产品描述Product description
◆FA1-6D系列是一款通用型的扳机开关，内部为快速动作结构，应用于对防尘不做要求的手持式电动工具和园林工具，如：搅拌器、电动钉枪、打草机、电链锯、电动割草机、电动扫雪机等。
◆FA1-6D series are one general type trigger switch, with with snap-action structure, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
产品特征Features
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 NoLock
→闭合锁定 Lock-on
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V78A
→最大冲击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端Input side:
→2×接线柱端子Pillar terminalsφ=2.8mm
→4×插入式端子可插入沾锡导线、带插片端子导线或铜包头导线
4×Push-in terminals for sold ered strands, strands with end sleeves or strands with end claws
◆输出端Output side:
→2×接线柱端子Pillar terminalsφ=2.8mm
→4×插入式端子可插入沾锡导线、带插片端子导线或铜包头导线
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
电气参数和认证 Electric Rating and Certification
