◆FDJ, FDM系列是迷你型的小型推拉开关，也叫滑动开关，应用于各类需要微电流档位控制的电器，如：迷你型螺丝起子、充电灯等。 ◆FDJ, FDM series are mini type slide switches, commonly for used in micro current appliances such as Mini Screwdrivers, Rechargeable Lights, etc.
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4 →电气耐久寿命 Electrical life endurance≥1E4 →最大电流 Max. current6A →接触电阻 Contact resistance≤30m Ohm →绝缘电阻 Insulation resistance≥7M Ohm →基本介电强度 Dielectric strength of function500V →加强介电强度 Diele ctric strength of reinforced500V →环境温度 Ambient temperature0°C~85°C →阻燃等级 FlammabilityUL 94V-0 →防护等级 Protection typeIP40 →适用于II类防护器具 Suitable for appliances of protection class II
