FDR-1300

FDR滑动(推拉)开关

FDR series Slide (Push-pull) Switches

产品描述Product description

◆FDR系列是一款专用型的弧型滑动开关，也叫推拉开关或推拨开关，应用于各类需要微电流档位控制的电器，如：直流充电电钻、直流充电螺丝起子、直流充电灯等。
◆FDR series are special arc type slide switches, commonly for used in micro current appliances such as DC Cordless Drills, DC Cordless Screwdrivers, DC Cordless Lights, etc.

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 24Vd.c0.5A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced500V
→环境温度 Ambient temperature0°C~85°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→焊接端子 Soldering terminals 4-φ=0.8mm
★本产品荣获实用新型专利，专利号：ZL201821372793.X
★Utility Model patented with the no. is ZL201821372793.X

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
